Applications

For use in conduit or other recognized raceways for service, feeder, and branch circuit applications as specified in the NEC®. Good choice for industrial applications where better insulation resistance to moisture and heat are desired. For use in wet or dry locations at temperatures up to 90°C. Sunlight-resistant.

  • branch circuit wiring
  • feeders
  • industrial
  • service entrance
  • wet or dry locations
Conductors

Stranded conductors

  • Uncoated, soft copper per ASTM B3 and ASTM B8
Insulation

Crosslinked polyethylene with SLiPWire™ Self-Lubricating Polymer

Industry Standards

UL 44: 125474
ASTM B3
ASTM B8
Federal Specification A-A-59544
NFPA 70 (National Electrical Code)
NEMA WC 70 Construction Requirements
RoHS/REACH Compliant

Surface Print

Sample: Crrowire-U SLiPWire™ 250 KMCIL (UL) XHHW-2 GRII FOR CT USE SR 600V XL

(Additional information may be included, markings vary by size.)

Colors
BlackWhiteRedOrangeYellowGreenBlueBrownGrey
